Product Summary

The TLV2462CDR is a family of low-power rail-to-rail input/output operational amplifiers specifically designed for portable applications. The input common-mode voltage range extends beyond the supply rails for maximum dynamic range in low-voltage systems. This rail-to-rail dynamic range and high output drive make the TLV2462CDR ideal for buffering analog-to-digital converters.

Parametrics

Absolute maximum ratings: (1)Supply voltage, VDD: 6 V; (2)Differential input voltage, VID: 0.2 V to VDD + 0.2 V; (3)Input current, II (any input): ± 200 mA; (4)Output current, IO: ± 175 mA; (5)Total input current, II (into VDD+): 175 mA; (6)Total output current, IO (out of GND): 175 mA; (7)Operating free-air temperature range, TA: C suffix: 0°C to 70°C, I and Q suffix: 40°C to 125°C, M suffix: 55°C to 125°C; (8)Maximum junction temperature, TJ: 150°C; (9)Storage temperature range, Tstg: 65°C to 150°C; (10)Lead temperature 1,6 mm (1/16 inch) from case for 10 seconds: 260°C.

Features

Features: (1)Rail-to-Rail Output Swing; (2)Gain Bandwidth Product: 6.4 MHz; (3)±80 mA Output Drive Capability; (4)Supply Current: 500 μA/channel; (5)Input Offset Voltage: 100 μV; (6)Input Noise Voltage: 11 nV/√Hz; (7)Slew Rate: 1.6 V/μs; (8)Micropower Shutdown Mode: 0.3 μA/Channel.

Diagrams

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
TLV2462CDR
TLV2462CDR

Texas Instruments

Operational Amplifiers - Op Amps Dual Low-Power Rail-to-Rail I/O

Data Sheet

0-1: $1.38
1-25: $1.06
25-100: $0.97
100-250: $0.80
TLV2462CDRG4
TLV2462CDRG4

Texas Instruments

Operational Amplifiers - Op Amps Dual Low-Power Rail-to-Rail I/O

Data Sheet

0-1800: $0.64
1800-2000: $0.61
2000-2500: $0.61
2500-5000: $0.58
