Product Summary

The UC3845AD Current Mode PWM Controller is a pin for pin compatible improved version of the UC3842/3/4/5 family. Providing the necessary features to control current mode switched mode power supplies, this UC3845AD has the following improved features. Start up current is guaranteed to be less than 0.5mA. Oscillator discharge is trimmed to 8.3mA. During under voltage lockout, the output stage can sink at least 10mA at less than 1.2V for VCC over 5V.

Parametrics

UC3845AD absolute maximum ratings: (1)Supply Voltage (Low Impedance Source): 30V; (2)Supply Voltage (ICC mA): Self Limiting; (3)Output Current: ±1A; (4)Output Energy (Capacitive Load): 5μJ; (5)Analog Inputs (Pins 2, 3): -0.3V to +6.3V; (6)Error Amp Output Sink Current: 10mA; (7)Power Dissipation at TA ≤ 25℃ (DIL-8): 1W; (8)Storage Temperature Range: -65℃ to +150℃; (9)Lead Temperature (Soldering, 10 Seconds): 300℃.

Features

UC3845AD features: (1)Optimized for Off-line and DC to DC Converters; (2)Low Start Up Current (<0.5mA); (3)Trimmed Oscillator Discharge Current; (4)Automatic Feed Forward Compensation; (5)Pulse-by-Pulse Current Limiting; (6)Enhanced Load Response Characteristics; (7)Under-Voltage Lockout With Hysteresis; (8)Double Pulse Suppression; (9)High Current Totem Pole Output; (10)Internally Trimmed Bandgap Reference; (11)500kHz Operation; (12)Low RO Error Amp.

Diagrams

 UC3845AD  block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
UC3845AD1
UC3845AD1

STMicroelectronics

Other Power Management RO 511-UC3845BD 9/04

Data Sheet

Negotiable
UC3845AD8TR
UC3845AD8TR

Texas Instruments

Current Mode PWM Controllers Current-Mode PWM Controller

Data Sheet

0-1: $0.70
1-25: $0.64
25-100: $0.56
100-250: $0.49
UC3845ADG4
UC3845ADG4

Texas Instruments

Current Mode PWM Controllers Current-Mode PWM Controller

Data Sheet

0-1: $0.85
1-25: $0.68
25-100: $0.62
100-250: $0.55
UC3845ADTR
UC3845ADTR

Texas Instruments

Current Mode PWM Controllers Current-Mode PWM Controller

Data Sheet

0-1730: $0.33
1730-2000: $0.31
2000-2500: $0.31
2500-5000: $0.30
UC3845ADTRG4
UC3845ADTRG4

Texas Instruments

Current Mode PWM Controllers Current-Mode PWM Controller

Data Sheet

0-1730: $0.33
1730-2000: $0.31
2000-2500: $0.31
2500-5000: $0.30
UC3845ADW
UC3845ADW

Texas Instruments

Current Mode PWM Controllers Current-Mode PWM Controller

Data Sheet

Negotiable
UC3845ADWG4
UC3845ADWG4

Texas Instruments

Current Mode PWM Controllers Current-Mode PWM Controller

Data Sheet

Negotiable
UC3845ADWTR
UC3845ADWTR

Texas Instruments

Current Mode PWM Controllers Current-Mode PWM Controller

Data Sheet

Negotiable
