Product Summary

The PME271M610MR30 is intended for use as interference suppressors in X1 or X2 (across-the-line) applications. Multi-layer metallized paper. Encapsulated and impregnated in self-extinguishing material meeting the requirements of UL 94V-0. The impregnated paper ensures excellent stability giving outstanding reliability properties, especially in applications having continuous operation.

Parametrics

Absolute maximum ratings: (1)Rated voltage VAC, 50/60Hz: 275; (2)Capacitance range: 0.001-0.6 μF; (3)Temperature range: -40 to +110 °C; (4)Climatic category IEC: 40/110/56/B; (5)Capacitance tolerance: ± 10% for C > 0.1 μF, code K; (6)Approvals: S, N, D, FI, VDE, SEV, IMQ, UL, CSA.

Features

Features: (1)Good resistance to ionisation due to impregnated dielectric; (2)High dU/dt capability; (3)Small dimensions; (4)Safety approvals for worldwide use; (5)Self-extinguishing UL 94V-0 encapsulation material.

Diagrams

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
PME271M610MR30
PME271M610MR30
Kemet
Film Capacitors 275volts 0.10uF 20% LS 20.3mm
Data Sheet
0-1: $1.09
1-50: $0.95
50-100: $0.89
100-500: $0.82
Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
PME261EA5150KR30
PME261EA5150KR30
Kemet
Film Capacitors 630volts 0.015uF 10% LS 10.2mm
Data Sheet
0-800: $0.63
800-1000: $0.47
1000-2000: $0.42
2000-5000: $0.38
PME261JC6100KR30
PME261JC6100KR30
Kemet
Film Capacitors 1000volts 0.10uF 10% LS 20.4mm
Data Sheet
0-1: $2.30
1-50: $2.00
50-100: $1.87
100-500: $1.73
PME261JB5330KR30
PME261JB5330KR30
Kemet
Film Capacitors 1Kvolts 0.033uF 10% LS 15.2mm
Data Sheet
0-1: $1.31
1-50: $1.14
50-100: $1.06
100-500: $0.98
PME261KA4820KR30
PME261KA4820KR30
Kemet
Film Capacitors 400volts 8200pF 10% LS 10.2mm
Data Sheet
0-1350: $0.40
1350-2000: $0.36
2000-5000: $0.33
5000-10000: $0.29
PME261EB5680KR30
PME261EB5680KR30
Kemet
Film Capacitors 630volts 0.068uF 10% LS 15.2mm
Data Sheet
0-500: $1.10
500-1000: $0.83
1000-2000: $0.73
2000-5000: $0.66
PME261EB5470KR30
PME261EB5470KR30
Kemet
Film Capacitors 630volts 0.047uF 10% LS 15.2mm
Data Sheet
0-500: $0.97
500-1000: $0.73
1000-2000: $0.65
2000-5000: $0.58
